SOLUTION

Optical module process solution

Product Introduction and Process Features

The function of an optical module is photoelectric conversion, which is used as a carrier
for transmission between switches and devices. The transmitting end converts electrical
signals into optical signals, which are then transmitted through optical fibers. The
receiving end then converts the optical signals into electrical signals. Optical modules are
more efficient and secure than transceivers.

POFV process

Long and Short Gold
Fingers/Graded Gold
Finger Design

Blind/buried
hole design

Impedance control
5% -7%

P molding size
control 50um
tolerance

Golden finger
size control
within+/-30um

Characteristics of optical module technology
