SOLUTION

Planar Transformer Process Solution

Advantages of planar transformers

High

Small size

High efficiency

Good parameter
repeatability

Wide operating
frequency range

Wide working
temperature range

Good insulation

Low leakage
sensation

Good heat
conduction

Low EMI
radiation

The plate conductors of a
planar transformer are
actually some planar
conductors, resulting in a
high current density

The use of small magnetic
cores can correspondingly
reduce the volume

Efficiency can reach
98%~99%

Because the winding
structure is fixed and easy
to pre process, the
parameters are stable

The frequency can range
from 50kHz to 2MHz

Working temperature is
-40 ℃ to 130 ℃

A planar transformer is
composed of conductive
circuits and insulation
sheets

Approximately 0.2% of the
primary inductance

Short hot channel distance
and low temperature rise

Good magnetic core
shielding can reduce
radiation to a very low level

Process characteristics of planar transformers

Thick copper
from 2-6oz

Linewidth (coil)
consistency

Uniformity of
thickness

Media thickness
uniformity
